Cobre NU 2,5 MM RECEBIDO R250mP4,5
Referência Nexans 10132168
- Packaging: Coil (250m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: - mm²
- Number of round wires: -
- Length: 250 m
Cobre NU MOBIWAY™ 1x25 D50m
Referência Nexans 10186364
- Packaging: Drum (50m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: - mm²
- Number of round wires: 7
- Length: 50 m
Cobre NU 6 (S) RECEBIDO D500 P9KM
Referência Nexans 10188530
- Packaging: Drum (500m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 6 mm²
- Number of round wires: 7
- Length: 500 m
Cobre NU 6 (S) RECEBIDO GL
Referência Nexans 10188401
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 6 mm²
- Number of round wires: 7
- Length: - m
Cobre NU 10 (S) RECEBIDO GL
Referência Nexans 10188403
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 10 mm²
- Number of round wires: 7
- Length: - m
Cobre NU 16 (S) RECEBIDO GL
Referência Nexans 10188534
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 16 mm²
- Number of round wires: 7
- Length: - m
Cobre NU 25 MM2 (S) GL
Referência Nexans 10044912
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 25 mm²
- Number of round wires: 7
- Length: - m
Cobre NU 25 MM2 (S) R50mP3,6
Referência Nexans 10044911
- Packaging: Coil (50m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 25 mm²
- Number of round wires: 7
- Length: 50 m
Cobre NU 25 MM2 (S) RECEBIDO R100mP3,6
Referência Nexans 10044910
- Packaging: Coil (100m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 25 mm²
- Number of round wires: 7
- Length: 100 m
Cobre NU 25 (S) RECEBIDO 10m P180U
Referência Nexans 10266114
- Packaging: Coil (10m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 25 mm²
- Number of round wires: 7
- Length: 10 m
Cobre NU 25 (S) RECEBIDO R25m P80U
Referência Nexans 10266117
- Packaging: Coil (25m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 25 mm²
- Number of round wires: 7
- Length: 25 m
Cobre NU 25 MM2 (S) RECEBIDO D500
Referência Nexans 10189589
- Packaging: Drum (500m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 25 mm²
- Number of round wires: 7
- Length: - m
Cobre NU RECEBIDO 1x25 R25m P2km
Referência Nexans 10263172
- Packaging: Coil (25m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 25 mm²
- Number of round wires: 7
- Length: 25 m
Cobre NU MOBIWAY™ 1x25 D100m
Referência Nexans 10163453
- Packaging: Drum (100m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 25 mm²
- Number of round wires: 7
- Length: 100 m
Cobre NU 35 MM2 (S) RECEBIDO GL
Referência Nexans 10132149
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 35 mm²
- Number of round wires: 7
- Length: - m
Cobre NU 50 (S) RECEBIDO GL
Referência Nexans 10226463
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 50 mm²
- Number of round wires: 19
- Length: - m
Cobre NU 70 (S) RECEBIDO GL
Referência Nexans 10226524
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 70 mm²
- Number of round wires: 19
- Length: - m
Cobre NU 74,9 MM2 (S) RECEBIDO GL
Referência Nexans 10132151
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 74,9 mm²
- Number of round wires: 19
- Length: - m
Cobre NU 95 (S) RECEBIDO GL
Referência Nexans 10226525
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 95 mm²
- Number of round wires: 19
- Length: - m
Cobre NU 120 (S) RECEBIDO GL
Referência Nexans 10226526
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 120 mm²
- Number of round wires: 37
- Length: - m
Cobre NU 150 (S) RECEBIDO GL
Referência Nexans 10226527
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 150 mm²
- Number of round wires: 37
- Length: - m
Cobre NU 185 (S) RECEBIDO GL
Referência Nexans 10226528
- Packaging: Cut to length (m)
- Conductor material: Bare annealed copper stranded
- Conductor cross-section: 185 mm²
- Number of round wires: 37
- Length: - m
COBRE NU ENDURECIDO 5,5 MM2 (S) GL
Referência Nexans 10132123
- Packaging: Cut to length (m)
- Conductor material: Hard copper
- Conductor cross-section: 5,5 mm²
- Number of round wires: 7
- Length: - m
COBRE NU ENDURECIDO 10,8 MM2 (S) GL
Referência Nexans 10132124
- Packaging: Cut to length (m)
- Conductor material: Hard copper
- Conductor cross-section: 10,8 mm²
- Number of round wires: 7
- Length: - m
COBRE NU ENDURECIDO 14,1 MM2 (S) GL
Referência Nexans 10132125
- Packaging: Cut to length (m)
- Conductor material: Hard copper
- Conductor cross-section: 14,1 mm²
- Number of round wires: 7
- Length: - m
COBRE NU ENDURECIDO 27,6 MM2 (S) GL
Referência Nexans 10132128
- Packaging: Cut to length (m)
- Conductor material: Hard copper
- Conductor cross-section: 27,6 mm²
- Number of round wires: 7
- Length: - m
COBRE NU ENDURECIDO 29 MM2 (S) GL
Referência Nexans 10044942
- Packaging: Cut to length (m)
- Conductor material: Hard copper
- Conductor cross-section: 29,2 mm²
- Number of round wires: 19
- Length: - m
COBRE NU ENDURECIDO 29 MM2 (S) R50m P1,8
Referência Nexans 10044941
- Packaging: Coil (50m)
- Conductor material: Hard copper
- Conductor cross-section: 29,2 mm²
- Number of round wires: 19
- Length: 50 m
COBRE NU ENDURECIDO 48 MM2 (S) GL
Referência Nexans 10132132
- Packaging: Cut to length (m)
- Conductor material: Hard copper
- Conductor cross-section: 48,3 mm²
- Number of round wires: 19
- Length: - m
COBRE NU ENDURECIDO 93 MM2 (S) GL
Referência Nexans 10132145
- Packaging: Cut to length (m)
- Conductor material: Hard copper
- Conductor cross-section: 93,3 mm²
- Number of round wires: 19
- Length: - m
COBRE NU ENDURECIDO 181,6 MM2 (S) GL
Referência Nexans 10132148
- Packaging: Cut to length (m)
- Conductor material: Hard copper
- Conductor cross-section: 181,6 mm²
- Number of round wires: 37
- Length: - m
Descrição
Descrição
Padrões
-
InternacionalNexans specification
Utilização
Cabos destinados à ligação à terra de massas (ligação à terra em edifícios).
O cabo de Cobre Nu, é um cabo de cobre especialmente indicado para a realização de instalações de conexão à terra de dispositivos elétricos em instalações quer domésticas quer industriais. Permite uma excelente transmissão de energia.
O cabo instala-se conexão à terra em instalações quer domésticas como industriais
Descrição
Núcleo: cobre duro ou recozido.
Os cabos de terra endurecido cumprem a norma NF C 34-110-3.
Os cabos de terra recozidos (Cu ETP1, puro 99,9%) cumprem a norma NF EN 60-228
Consulte-nos para preços
